細節
TYPE
Direct Drive

TURNTABLE SPEEDS
33.3, 45rpm

WOW & FLUTTER
<0.1%

TURNTABLE PLATTER
POM (Polyoxymethylene)

PLATTER DIAMETER
305mm

PLATTER WEIGHT
2.2kg

AUDIO OUT
RCA Phono/Line Level (Switchable)

BLUETOOTH
SBC/aptX/aptX HD

POWER SUPPLY
AC 100-240V, 60/50Hz

POWER CONSUMPTION
5.5W

MAX POWER CONSUMPTION
20W

STANDBY POWER CONSUMPTION
<0.25W

DIMENSIONS (W X H X D)
435 x 139 x 368mm

WEIGHT
10.9kg

PHONO STAGE GAIN @1KHZ
42dB

PHONO STAGE NOMINAL OUTPUT
250Vrms

PHONO STAGE INPUT NOISE (A-WEIGHTED)
0.1u Vrms

PHONO STAGE RIAA CURVE ACCURACY
*+/- 0.3dB 30Hz-20kHz

PHONO STAGE SIGNAL/NOISE RATIO
>90dB

PHONO STAGE THD+N 1KHZ
0.0025%

PHONO STAGE INPUT IMPEDANCE
47Ω

PHONO STAGE INPUT CAPACITANCE
100pF

TONEARM TYPE
Static Balanced Tonearm w/ detachable Headshell

TONEARM EFFECTIVE LENGTH
221.5mm

TONEARM OVERHANG
19mm

TONEARM EFFECTIVE MASS
19.6g

TONEARM COMPATIBLE CARTRIDGE WEIGHTS
4.5-12g

CARTRIDGE
High Output Moving Coil

CARTRIDGE FREQUENCY RESPONSE
*+/- 1dB 30Hz-20kHz

CARTRIDGE STYLUS
Elliptical

CARTRIDGE CANTILEVER
Aluminium

CARTRIDGE OUTPUT LEVEL
2mV @1kHz

CARTRIDGE TRACKING FORCE
2g

CARTRIDGE RECOMMENDED LOAD
47Ω
