Specifications
Peak Pulse Power
1300 W
Rated Power
8Ω 302W
4Ω 360W
Output Voltage max.
72 V peak
Output current max.
23 A peak
Input Impedance
10 kΩ, XLR
Input Sensitivity
2,2 V, 302 W, 8 Ω
S/N ratio (unweighted)
117 dB
S/N ratio (A-weighted)
120 dB
Frequency Response
DC - 130 kHz
Distortion
<0.004%, 4 Ω, 1 kHz, 50 W
Damping Factor
200 (4 Ω)
Power Consumption
4 VA sleep mode
47 VA Idle Mode
480 VA max.
Line Voltage (factory setting)
230 / 115 Vac, 50 / 60 Hz
Dimensions (W x H x D)
320 x 380 x 570 mm
Weight
30 kg
