Electrical Specification
Inputs
6 inputs, (XLR*1 pair, CD *2, high level/tape *2 Processor *1)
Output
1 Fixed Out, 2 pair of speaker terminals

Technical Specifications
Peak Pulse Power
450W @ Max Power
Power output
275W RMS @ 4 Ohms
180W RMS @ 8 Ohms
Input Impedance
XLR: 10k Ohms,
RCA: 10k Ohms,
High level: 50k Ohms,
Processor: 10k Ohms
Input Sensitivity
315mV
Output Impedance
100 Ohms
Output level
1Veff – 10Veff max
Output Voltage Max
85V peak
Output Current Max
25A peak
Frequency Response
DC – 400 kHz
THD
<0.001%
Channel Separation
90db
Damping Factor
300 (4 Ohms)
S/N
Weighted 110db / Unweighted 120db
