| 輸出電壓 |
220 – 240 V (50 – 60 Hz)
100 – 120 V (50 – 60 Hz) |
| 消耗功率 |
＜0.5 W standby
60 W device in operation |
| 類比輸出 |
1 × balanced (XLR)
1 × unbalanced (RCA) |
| 頻率響應 |
0 – 200 kHz (DXD) |
| 總諧波失真 |
＜0.0005% (20 Hz – 20 kHz) |
| 訊噪比 |
＞140 dB |
| 聲道分離度 |
＞130 dB |
| 輸出阻抗 |
2 Ω balanced (XLR)
2 Ω unbalanced (RCA) |
| 輸出電壓 |
4 VRMS balanced (XLR)
2 VRMS unbalanced (RCA) |
| 最大輸出電流 |
1 A (limited by protection circuit) |
| 音量控制範圍 |
0 to – 79 dB in 1 dB steps |
| 數位輸入 |
AES/EBU, SPDIF-RCA, Optical, USB, Network |
| 數位輸出 |
AES/EBU, SPDIF-RCA, Clock-BNC |
| 數位規格 |
WAV, AIFF, FLAC, ALAC, DSF, DFF, DXD, MP3, AAC |
| 位元深度/取樣頻率 (max) |
AES/EBU:24 bit/192 kHz
SPDIF:24 bit/192 kHz
Optical:24 bit/ 96 kHz, 24 bit/384 kHz
USB:1 bit/5.64 MHz, 24 bit/384 kHz
Network:1 bit/5.64 MHz |
| 尺寸 |
480 × 167 × 450 mm
(W × H × D) |
| 重量 |
approx. 30 kg |
| LINK (remote turn-on) |
12 V control signal |
| USB 驅動 |
v1.22c for Win7
v1.611 for Win7
v2.26 for Win10 |
