| 輸入電壓 |
220 – 240 V (50 – 60 Hz)
100 – 120 V (50 – 60 Hz) |
| 消耗功率 |
＜0.5 W standby
idle 300 W / 200 W
max 1600 W |
| 增益 |
Dual:+ 26 dB
Mono:+ 32 dB |
| 輸出功率 |
600 W @ 8 Ω (2 × 150 W*)
1200 W @ 4 Ω (2 × 300 W*)
2000 W @ 2 Ω (2 × 600 W*)
*in dual mode |
| 脈衝功率 |
＞12,000 W |
| 頻率響應 (– 3 dB) |
0 – 2 MHz (0 – 1 MHz*)
*in dual mode |
| 總諧波失真 |
＜0.0003% at 50 W @ 4 Ω
(20 Hz – 20 kHz) |
| IM 失真 |
＜0.005% SMPTE
＜0.0006 CCIR |
| 訊噪比 |
108 dB (5 W @ 1 kHz) |
| 阻尼係數 |
＞10 000 |
| 最大輸出電流 |
120 A (limited) |
| 輸入端子 |
1 × balanced (XLR)
1 × unbalanced (RCA) |
| 輸入阻抗 |
2.3 kΩ balanced (XLR)
4.0 kΩ unbalanced (RCA) |
| 尺寸 |
560 × 306 × 585 mm
(W × H × D) |
| 重量 |
approx. 75 kg |
| LINK (remote turn-on) |
12 V control signal |
